Ulefone Armor 26 Ultra Walkie Talkie 5G Rugged Phone 120W 15600mAh 200MP+64MP +50MP NFC 6.78″ FHD+ Waterproof Mobile Smartphone – 509

1： Import duties and taxes are the buyer’s responsibility, our price does not include any custom taxes. If the parcel get strict inspected by custom. You still need to pay tax to clear custom. We won’t bear the customs taxes. The cost of return would be on customer due to reject customs clearance.

2: EU customer:Items shipped from outside of EU countries with a goods value above EUR 150. A VAT will be required for customs clearance, and the cost is at buyer’s expense.

3：Orders from the EU countries will be shipped randomly from China warehouse or French warehouse or German warehouse.（*Customers need to pay VAT）

Notice for Overseas Warehouse Shipment: PO.BOX address is not accepted, Receiver detail address max length cannot exceed 128 characters. Some countries and overseas territories cannot deliver. If you have any questions, please contact

 Armor 26 Ultra Walkie-Talkie Version Specifications

15600mAh Battery(Rated capacity 7800mAh with high voltage 7.74V is equivalent to 15600mAh capacity.

120W, 20V/6A

NFC,IR Blaster

6.78-inch，1080 x 2460 FHD+

MediaTek Dimensity 8020

24GB RAM= 12GB LPDDR4X +12GB virtual RAM

512GB ROM, UFS3.1

Main Rear Camera:200MP

     Details: Samsung HP3 CMOS sensor, 0.56μm, 7 piece lens, FOV 84.7°, ƒ/1.79 large aperture

Night Vision Camera:64MP

     Details: OV64B1B CMOS sensor, ƒ/1.79 large aperture

Ultra-wide Angle Lens:50MP

     Details: Hi5022Q CMOS sensor,FOV 117.3°, ƒ/2.2 large aperture

3.2X Optical Zoom Telephoto Lens:8MP

     Details: Hi847 CMOS sensor,3.2X Optical Zoom, 30x Digital Zoom, Supports Zoom EIS

Front Camera :50MP

5G/4G/3G/2G

*Not compatible with AT&T, Cricket, Sprint,Verizon, Boost Mobile

*Some network carriers have not been displayed because their 5G networks are not yet in mass commercial use. If you have participated in this carrier’s testing program, please check with the carrier about the 5G frequencies they use, so that you can check whether Armor 26 Ultra 5G supports their network.

5G: 5G NR Sub6: N1/2/3/5/7/8/20/25/28/38/40/41/66/71/77/78/79

4G: FDD-LTE: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28A/28B/66/71

TDD-LTE: B34/38/39/40/41

3G: WCDMA: B1/2/4/5/6/8/19

2G: GSM: B2/3/5/8CDMA: BC0/BC1/BC10

 Dual Modes Mobile Radio

Digital and Analog Modes

Armor 26 Ultra features dual modes mobile radio, digital and analog, allowing fast and reliable push-to-talk communication. The handset supports multiple device connections, making communication between team members more efficient and convenient.

 Optional UHF or VHF Antenna

Supporting both UHF and VHF radios for flexible use based on actual conditions,

•  the UHF band is suitable for short-distance communication, providing stronger penetration and clear and reliability while the VHF band is for long-distance communication, offering a wider coverage range and signal attenuation.
• Both UHF and VHF antennas are detachable, allowing you to replace each other as needed to achieve better signal reception quality or detach for easy to take.

Equivalent 15600mAh Battery

Keep Going for A Week

* This product uses dual-cell series connection design:

Typical capacity: 7800 mAh (7.74V), equivalent to 15600 mAh (3.87V)

Typical energy:60.372 Wh

Rated capacity 7800mAh with high voltage 7.74V is equivalent to 15600mAh capacity.

 120W Flash Charging

The Armor 26 Ultra leverages the full potential of 120W flash charging, you are never left waiting for your device to power up – in just 5 minutes of charging, prepare for an astonishing 9 days standby time, allowing you to stay connected and entertained on the go. The charger supports PD (PPS) protocol and Type C to Type-C cable, and can fast charge the iPhone.

 33W Fast Dock Charging | 2-in-1 Charger Stand

 Reverse Charging Viable

| 15600mAh Power Tank

 200MP Mega Imaging System

All-Scenario Pro Photography

200 Megapixels quad-camera setup takes mobile photography to another peak. Meets professional photography day or night with quality shots that with the finest details just like what you see in reality. No longer limited by distance or scenes, the camera system is ready for full support.

 200MP Mega Main Camera

Details Burst Off the Images

The most megapixels, 200MP camera quality, empowered by Samsung ISOCELL HP3, featuring a 1/1.4-inch ultra-large sensor with ƒ/1.79 aperture, bringing more light to deliver masterpieces fully rich in color and subtlest detail. Fusion with the Ulefone EIS algorithm, mega visual at your every shot.

 3.2x Optical Zoom Telephoto Lens

Bring Scenes Closer Blur-Freely

Shoot near, shoot far, without compromising on image quality, the 3.2x optical lens makes it easy. The telephoto with up to 76mm* equivalent focal length and the cooperation with main camera via SAT technology, creates images greatly better than shots taken with a standalone traditional telephoto lens. Moreover, the innovative ZOOM EIS technology always keeps your ultra-telephoto shots steady and blur-free.

 50MP Ultra-wide Macro Camera

Fusion of Wide Angle and Macro

50MP ultra-wide lens featuring up to 117.3° field of view (FOV) expands your horizons. Enhanced by macro and EIS algorithm, every shot is much more detailed, steady and immersive, and will not regret confined spaces but making landscapes and cityscapes wonders come to life.

 64MP Night Vision Camera

NightElf Ultra 3.0 Algorithm

The 64MP Night Vision Camera takes night and low-light photography to the next level, paired with OMNIVISION’s advanced OV64B sensor and Ulefone’s NightElf Ultra 3.0 algorithm. Shoot with exceptional clarity and detail, transforming darkness into vibrant images.

 50MP Ultra Front Camera

Breathtaking Self-portraits

Capture moments in stunning detail with a 50MP Ultra Front Camera. Enjoy sharp video calls and selfies with an 80.4° wide-angle view and superior low-light performance, thanks to the f/2.25 aperture. Combined with EIS technology, say goodbye to average selfies.

 IP68/IP69K, MIL-STD-810H

Ulefone Defender Structure

Armor 26 Ultra is splash, water, and dust resistant and was tested under controlled laboratory conditions with a rating of IP68 under IEC standard 60529 (maximum depth of 1.5 meters up to 30 minutes). Charger and accessories are not water-resistant. Splash, water and dust resistance are not permanent and might decrease as a result of normal wear. Do not attempt to charge a wet Armor 26 Ultra. Liquid damage not covered under warranty.

 121dB Thunder Speaker

With a 3 watts output power and a loudness of 121 dB, the speaker in 34mm diameter delivers an exceptionally powerful and crisp dynamic audio performance, providing great volume and clear sound in intercom communications and media playback.

 5G Network

Wider, Swifter, Smarter

Cutting-edge 5G technology empowers lightning-fast download and upload speeds, ultra-low latency, and enhanced network capacity. 5G technology meets the urgent needs of efficient transmission of massive data, low-latency interaction, large-scale device connection and highly reliable security services, bringing a more convenient, intelligent and efficient new life and work mode.

*Not compatible with AT&T, Cricket, Sprint,Verizon, Boost Mobile

*Some network carriers have not been displayed because their 5G networks are not yet in mass commercial use. If you have participated in this carrier’s testing program, please check with the carrier about the 5G frequencies they use, so that you can check whether Armor 26 Ultra 5G supports their network.

 MediaTek Dimensity 8020 5G

A Leap in Experience

The Armor 26 Ultra, powered by the MediaTek Dimensity 8020, offers a robust 5G experience with its 8-core CPU and advanced Arm Mali-G77 GPU, delivering excellent gaming and video performance for a swift and uninterrupted internet connection.

 Up to 24GB RAM + 512GB ROM

24GB RAM=12GB + 12GB Virtual RAM

Fast and Vast, Limitless Performance

No apps freeze at all! Features up to 24GB of RAM, generous 512GB of internal storage, and expandable up to 2TB, Armor 26 Ultra still works smoothly and has ample storage to meet your needs after several years. With UFS 3.1 flash memory technology, the device offers a significant boost in read and write speeds—4x faster reading and 5x faster writing than UFS 2.1, which enhances the data performance and efficiency.

*The micro SD card is not included, and need to be purchased separately. The virtual memory can be activated in Settings at your will.

 6.78″ FHD+ 120Hz Display

Hyper-realistic Visuals

6.78-inch large screen provides an immersive viewing experience for multimedia. Boasting a resolution of 1080 x 2460 pixels, great sharpness and detail with lifelike colors burst off the display. 120Hz ultra-high refresh rate makes every motion smooth and fluid especially when delving into the world of gaming and in your favorite streams.

About Power charger

1 Please choose EU plug or US plug when placing an order. （ * No other plug specification are available）

2： If you have any questions about the plug of the charger, please contact customer services in advance. Please note that the plug of the charger is not within the scope of After-Sales services.

Armor 26 Ultra Walkie-Talkie Version Specifications

Physical Characteristics

Color

Black

Material

PC

USB

Type-C, USB 3.1 Gen 1(Device: USB 3.1 Gen 1, Host: USB 2.0)

Expansion Connector

uSmart Expansion Connector, supporting uSmart series accessories.

Card Slots

3, 1x Nano-SIM + 1x Nano-SIM + 1x microSD

Keys

Right：Power button(Fingerprint)+Volume button + SOS Key，Left: Custom Key(default PTT Key)

Size & Weight

Product Size

179 x 83 x 25.5 mm

Product Weight

617.8 g

Package Size

198 x 108 x 97 mm

Package Weight

1147 g

Product size and weight may vary by configuration, manufacturing process and measurements. All specifications are     subject to the actual product.

Ruggedness

Certification

IP68/IP69K/MIL-STD-810H

Splash, Water, and Dust Resistant

Maximum depth of 2 meters up to 30 minutes

Drop resistance

Up to 1.5M tall

Working Temperature

-20℃ – 55 ℃ (-4℉ – 131℉)

Display

Screen Size

6.78-inch

Screen Resolution

1080 x 2460 FHD+

Aspect Ratio

20.5:9

PPI

396

Color Depth

8bit, 16.7M

Refresh Rate

120Hz

Screen-to-Body Ratio

84%

Multi-touch

10

Processor

CPU Model

MediaTek Dimensity 8020

Main frequency

2.6GHz

CPU Core

8, 4 x Arm Cortex-A78, 4 x Arm Cortex-A55

GPU

Arm Mali-G77 836MHz

RAM & Storage

RAM

24GB=12GB LPDDR4X +12GB virtual RAM(The virtual RAM can be activated in Settings at your will. )

Storage

512GB UFS3.1

Max. Expansion Supported

2TB

Rear Camera

Rear Camera Numbers

4

Main Rear Camera

Pixel: 200MP

Details: Samsung HP3 CMOS sensor, 0.56μm, 7 piece lens, FOV 84.7°, ƒ/1.79 large aperture

Night Vision Camera

Pixel: 64MP

Details: OV64B1B CMOS sensor, ƒ/1.79 large aperture

Ultra-wide Angle Lens

Pixel: 50MP

Details: Hi5022Q CMOS sensor,FOV 117.3°, ƒ/2.2 large aperture

3.2X Optical Zoom Telephoto Lens

Pixel: 8MP

Details: Hi847 CMOS sensor,3.2X Optical Zoom, 30x Digital Zoom, Supports Zoom EIS

Flash

4

Video Recording Resolution

4K@30fps, FHD@30fps, HD@30fps, VGA@30fps

Special Features

Normal mode, Night Vision Mode, Film Mode, 200MP Mode, Night Mode, Gif, Portrait, Pro Mode, Panorama, Slow Motion, Time Lapse, Macro, Intelligent Scanning

Front Camera

Pixel

50MP

Details

Details: Hi5022Q CMOS sensor, 1.0μm, 5 piece lens, FOV 80.4°, ƒ/2.25 large aperture

Video Recording Resolution

FHD@30fps, HD@30fps, VGA@30fps

Special Features

Normal mode, Film, Gif, Portrait

Battery & Charging

Capacity

15600mAh (Equivalent to 7800mAh, 7.74V)

Watt Hours Per Battery

60.372 Wh

Battery Type

Li-polymer battery

Charging Details

120W, 20V/6A

Dock Charging

Support, 33W

Standby Time

1750 Hours

Talk Time

56 Hours

Network & Connectivity

Card Type

Nano+Nano+microSD

Cellular

5G/4G/3G/2G

*Not compatible with AT&T, Cricket, Sprint,Verizon, Boost Mobile

*Some network carriers have not been displayed because their 5G networks are not yet in mass commercial use. If you have participated in this carrier’s testing program, please check with the carrier about the 5G frequencies they use, so that you can check whether Armor 26 Ultra supports their network.

Band Details

5G: 5G NR Sub6: N1/2/3/5/7/8/20/25/28/38/40/41/66/71/77/78/79

4G: FDD-LTE: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28A/28B/66/71

TDD-LTE: B34/38/39/40/41

3G: WCDMA: B1/2/4/5/6/8/19

2G: GSM: B2/3/5/8CDMA: BC0/BC1/BC10

Standby Mode

Dual sim dual standby

VoNR

Support

VoLTE

Support

WiFi

2.4G/5G/WiFi 6, 802.11 ax/ac/a/b/g/n

Bluetooth Version

BT5.1

Navigation

(L1+L5) GPS/GLONASS/Beidou/Galileo/QZSS

Radio Communication

Type

Dual-mode (digital/analog) dual-band (UHF/VHF), dual-slot, support DMR

Frequency Range

UHF Band: 400MHz-470MHz

VHF Band: 137MHz-172MHz

Operating Range

UHF Band: 0-22KM

VHF Band: 0-30KM

App

PrizeInterPhone

Shortcut Key

PTT Key (One-key to talk)

Audio

Speaker Numbers

1

Speaker Model

SB9754

Speaker Power

3W

Smart PA

AW88394

Loudness

Max 121dB

Equivalent Cavity

8cc

Security

Fingerprint ID

Support

Face Unlock

Support

System & Features

Android Version

Android 13

Language

Indonesian, Malay, Catalan, Czech, Danish, German, Estonian, English, Spanish, Filipino, French, Croatian, Italian, Latvian, Lithuanian, Hungarian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Finnish, Swedish, Vietnamese, Greek, Turkish, Bulgarian, Russian, Serb, Ukrainian, Armenian, Hebrew, Urdu, Arabic, Persian, Hindi, Bengali, Thai, Korean, Burmese, Japanese, Simplified Chinese, Traditional Chinese

Blinking Notification Light

Support, red/green/blue light

Battery Status Light

Support

Audio Format Supported

MID/FLAC/MP3/M4A/AAC/AMR/OGG

Video Format Supported

MOV/MKV/3GP/MP4

Image Format Supported

GIF/JPEG/PNG/BMP

Text Format Supported

TXT/HTML

FM Radio

Support,headset-free FM radio

Cell Broadcast

Support

Sensor

Proximity Sensor, Gravity sensor, Light Sensor, Acceleration Sensor, Geomagnetic sensor, Gyro sensor, Coulomb counter, Pedometer, Air pressure sensor, Infrared sensor

Special Features

Underwater Camera

Support

Gloves Mode

Support

Digital Toolbox

Height Meter, Compass, Gradienter, Flashlight, Hanging Painting, Magnifier, Alarm bell, Plumb bob, Protractor, Noise Test, Pedometer, Barometer

OTG Function

Support, max 27W (9V3A) reverse charging

NFC

Support

IR Blaster

Support

Others

Packing List

1 x Phone

2 x Detachable Antenna（UHF+VHF ）

1 x AC Power Charger

1 x Type-C to Type-C Data cable (100cm)

1 x Protective Film (Pre-installed)

1 x SIM Needle

1 x Lanyard

1 x Multi-language User Manual

1 x Multi Function Instruction Card

1 x Walkie-Talkie User Guides

1 x Warranty Card

1 x Charging Instruction Card

1 x Safety Prompt Card

1 x Accessories Ecosystem Brochure

1 x Service Center APP Instructions

Product Certification

CE, FCC, IP68, IP69K, MIL-STD-810H, WEEE, ROHS.TAC, UN38.3,MSDS, IEC62133
