2024 4G Lte GPS industrial ip65 waterproof smartphone handheld rugged pda for windows 11 os  win11 rugged pda handheld terminal

ITEM DESCRIPTION detail

OS windows 10/11 home/pro/iot linux optional

CPU intel ADL-N, N100, 3.4G

RAM/ROM 8GB+256GB

LCD 6.5inch 720*1600 410nits

Touch screen 10 points touch,

Camera 5M+13M,mipi I/O

Power and battery battery  capacity 5000mAh, 7.6V

WWAN 4G LTE, 3G WCDMA, GSM LTE FDD: B1/B3/B7/B8/B20/B28A

   WCDMA: B1/B8

   GSM: B3/B8

GPS Beidou,GPS, glonass

wifi 802.11a b c, g,n wireless internet  Wireless AP ( Mobile AP )2.4G, 5G Intel Stone Peak3165  802.11ac 1×1+BT4.0

BLUETOOTH 5.0 version

NFC 13.56 MHz, distance 5cm or above support ISO14443 TYPE A standard/Mifare

SPEAKER 1.0 watt

Sensor 1. light sensor

2. G-sensor

size 180*85*22mm

weight 0.5kg

Multi-media

(Hardware decoding) Photo Viewer BMP, JPG, GIF, PNG

Video Format MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)

Audio Format MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license)

language multi language

interface

in/out port 1. type-c

2. USB 3.0*1

3. bottom charging pogopin 8 pin(4pin for charge)

4. back pogopin*1 USB*1+TTL*1

5. microphone

6. TF MAX512G

7. SIM card*2 or 1 TF+1*SIM card

Pogopin

definition 1.12 pin back, included 2USB*1, RS232*1, 3.3V, 5V output, 5V input

2. 4pin bottom, only for charging

casing material ABS/PC

button V+ -, Power, scan

2D barcode

module SE550 or Newland N1

UHF UM960, distance 3-6 meter

accessories 1. USB cable optional

2. charger                     3. handstrap

4. car holder optional

5. docking station optional

6. car charger optional

7. white box, no logo

proof rate 1. water proof IP65-IP67

2. Drapping proof 1.2 meter

Certification 1. 810G

2. CE,FCC

Temperature 1. storate temperature -25 to 80 degree

2. operation temperature -20 to 60 degree
